Place of Origin: | China |
---|---|
Brand Name: | Newradar Gas |
Certification: | ISO/DOT/GB |
Model Number: | N/A |
Minimum Order Quantity: | 1000 kilogram |
Price: | negotiation |
Packaging Details: | 10kg, 40kg or 50kg packed in the qualified gas cylinder or packed according to the demands. |
Delivery Time: | 15-25 working days after received your payment |
Payment Terms: | L/C, , T/T, Western Union, MoneyGram |
Supply Ability: | 3,00 ton per month |
Thermal Conductivity At STP: | (101.3 KPa And 0 °C) = 12.058 MW/(m·K | Heat Capacity At Constant Pressure (Cp): | (101.3 KPa And 21 °C) = 0.097 KJ/(mol·K) |
---|---|---|---|
MW:: | 146.06 | MF:: | F6S |
FilFilling Pressure: | 150-200 Bar | Other Names: | (OC-6-11)-Sulfurfluoride |
Application: | Circuit Breaker,high-voltage Transmission Line, CIS, Large Cable Coil, Mutual Inductor, Lightning Arrester. | Stability:: | Stable. Non-flammable. Explodes On Contact With Disilane. Reacts With Sodium. |
Highlight: | electric gas,purity plus specialty gases |
Sf6 Gass , Non Toxic Electronic Gases Cylinder Storage Reacts With Sodium
Description:
Sulfur hexafluoride gas is a colorless, odorless, non-toxic, non-combustible, non-corrosive inert gaseous material, widely used in conductive series, such as power switch, closed capacitor group, transformer, high power cable, Sensors, lightning rods and so on. Moreover, the efficacy of sulfur hexafluoride gas is also active in particle accelerators, X-ray, tracer analysis and non-metallic melting and other fields. In the process of human production and life, resulting in a large number of SF6 gas. However, sulfur hexafluoride gas is a greenhouse gas, a large number of emissions of the gas is bound to lead to environmental warming. Then reduce the sulfur hexafluoride emissions, will be containing sulfur hexafluoride tail gas conversion is to become a subject.
Vapors may cause dizziness or asphyxiation without warning. Vapors from liquefied gas are initially heavier than air and spread along ground. Contact with gas or liquefied gas may cause burns, severe injury and/or frostbite. Fire may produce irritating, corrosive and/or toxic gases.
7.Some may burn but none ignite readily. Containers may explode when heated. Ruptured cylinders may rocket.
Specifications:
1. Physical properties
Commodity | Sulfur hexafluoride |
Molecular Formula | SF6 |
CAS No. | 2551-62-4 |
UN No. | 1080 |
Hazardous Class | 2.2 |
Standard Package Container | 40L/150bar cylinder |
Cylinder Dimension | Φ219x1500mm |
Filling Weight | 50kg |
2. Typical technical data (COA)
Grade Classification | GB/T12022-2006 | High Purity |
4.5N | ||
(SF6) % | ≥99.9 | ≥99.995 |
Air % | ≤0.04 | ≤0.003 |
(CF4) % | ≤0.04 | ≤0.003 |
Water ppm | ≤5 | ≤1 |
Acidity ppm | ≤0.2 | ≤0.1 |
Hydrolyze fluoride(As HF) ppm | ≤1 | ≤0.2 |
Mineral oil ppm | ≤4 | ≤1 |
Toxicity | Non-tox. | Non |
Applications:
Electrical Industries Circuit Breaker |
leak detection and as a gaseous dielectric for transformers, condensers
|
As an inert gas
|
For the casting of magnesium.as an etchant in the semiconductor
|
As an inert filling |
Insulated glazing windows.
|
Dielectric medium |
SF6 is used in the electrical industry as a gaseous dielectric medium for high-voltage circuit breakers, switchgear, and other electrical equipment, often replacing oil filled circuit breakers (OCBs) that can contain harmful PCBs.
|
Medical use
|
SF6 is used to provide a tamponade or plug of a retinal hole in retinal detachment repair operations in the form of a gas bubble.SF6 is used as a contrast agent for ultrasound imaging. Sulfur hexafluoride microbubbles are administered in solution through injection into a peripheral vein.
|
Tracer compound |
Sulfur hexafluoride was the tracer gas used in the first roadway air dispersion model calibration; this research program was sponsored by the U.S. Environmental Protection Agency and conducted in Sunnyvale, California on U.S. Highway 101.Sulfur hexafluoride is also routinely used as a tracer gas in laboratory fume hood containment testing.
|
